Jinko Solar panel 550W for sale

Mechanical Characteristics

Cell type P-Type Mono-crystalline
No. of Cells 144 (6×24)
Dimensions 2274x1134x35mm
Weight 28.9kg
Front Glass Anti-Reflection Coating, High Transmission, Low Iron, Tempered Glass
Frame Anodized Aluminium Alloy
Junction Box IP68 Rated
Output Cables TUV 1×4.0mm2
(+): 400mm , (-): 200mm or Customized Length

Product Features

1. ldeal choice for large scale ground installation.

2. Optimized system performance due to module level current sorting.

3. Sand blowing test, salt mist test and ammonia test passed to endure harsh environments.

4. Special cutting and soldering technology leads to low hotspot risk.

5. Highly transparent self-cleaning glass brings additional yield and easy maintenance.

6. Selected encapsulating material and stringent production process control ensure
   the product is highly PlD resistant and snail trails free.

Deliver Reliable Performance Over Time

1.Manufacturer of crystalline silicon photovoltaic modules.

2.Fully automatic facility and world-class technology.

3.Rigorous quality control to meet the highest standard: ISO9001:2015；ISO14001:2015 ；

OHSAS:18001 2007

4.Tested for harsh environments (salt mist, ammonia corrosion and sand

blowing test:IEC 61701IEC 62716DIN EN 60068-2- 68).

5.Long term reliability tests.

6.2x100% EL inspection ensuring defect-free modules.

Linear Performance Warranty

Product Certification

Company profile

GENTAI INDUSTRIAL PTE. LTD. is the professional battery manufacturer in China mainland,we have 6 years experience in battery producing and the overseas marketing.

Main products: LiFePO4, Lead-acid Replace Battery, AGM-GEL Battery, Single Phase Off-Grid Solar Inverter, Three Phase Off-Grid Solar Inverter, Solar Panels, Portable Power Station, Solar Pump.
